HB9500M-9.5 Barrier Terminal Block, 2-Pin, 9.5mm, 32A
- Part number
- C601239
- Manufacturer
- KANGNEX
- Package
- Through Hole,P=9.5mm
Colour Black
Cover With cover plate
Max wire cross-section 4 mm²
Mounting type Straight
Number of rows 1
To order · Not on the shelf. Ask us and we will source it.
| Quantity | Unit price | Ext. price |
|---|---|---|
| 1+ | $1.00 | $1.00 |
Quantity
Extended price $1.00
- Colour
- Black
- Cover
- With cover plate
- Max wire cross-section
- 4 mm²
- Mounting type
- Straight
- Number of rows
- 1
- Operating temperature (°C)
- -40 ~ +105
- Pin count
- 2
- Pin location
- Side mount
- Pitch
- 9.5mm
- Rated current
- 32A
- Voltage rating (V)
- 750
- Wire gauge (AWG)
- 12 ~ 22
